RM-SM238-60
Base product: TRIPOD-MOUNTS
Non-Penetrating Roof Mount, 2-3/8 in x 60 in (60.3 mm x 1.5 m) pipe included
Specifications
Product classification
| Product Type | Tripod mount |
| Ordering Note | ANDREW® standard product (Global) |
| Warranty | One year |
General specifications
| Mounting | Non-penetrating |
| Pipe, quantity | 1 |
Dimensions
| Height | 1524 mm | 60 in |
| Width | 889 mm | 35 in |
| Length | 0.884 m | 2.9 ft |
| Pipe Length | 1524 mm | 60 in |
| Pipe Outer Diameter | 60.96 mm | 2.4 in |
Material specifications
| Material Type | Hot dip galvanized steel |
Packaging and weights
| Included | Brackets | Hardware | Pipe |
| Packaging quantity | 1 |
| Weight, net | 30 kg | 66.139 lb |
Regulatory compliance/certifications
| Agency | Classification |
CHINA-ROHS
|
Above maximum concentration value |
| ISO 9001:2015 | Designed, manufactured and/or distributed under this quality management system |
| ROHS | Compliant/Exempted |
| UK-ROHS | Compliant/Exempted |
