ACCURET-A11
Actuator, AISG 1.1 default protocol
Features and benefits
- Connects to the base station antenna for remote electrical tilt
- Easy to install; no tools required
- Easily mounts to back of antenna
- Factory set to AISG 1.1 mode
Specifications
Product classification
| Product Type | RET actuator |
General specifications
| AISG Input Connector | 8-pin DIN Male |
| AISG Input Connector Quantity | 1 |
| AISG Output Connector | 8-pin DIN Female |
| AISG Output Connector Quantity | 1 |
| Color | Black |
Dimensions
| Height | 205 mm | 8.071 in |
| Width | 125 mm | 4.921 in |
| Depth | 50 mm | 1.969 in |
Electrical specifications
| Input Voltage | 10–30 Vdc |
| Adjustment Cycles, minimum | 10000 cycles |
| Adjustment Time, full range, maximum | 30 s |
| Electromagnetic Compatibility (EMC) | CFR 47 Part 15, Subpart B, Class A | EN 55022 |
| Interface Protocol Signal | RS-485 |
| Protocol | AISG 1.1 |
Material specifications
| Material Type | ABS |
Environmental specifications
| Operating Temperature | -40 °C to +70 °C (-40 °F to +158 °F) |
| Climatic Sequence Test Method | IEC 60068-2-14 |
| Cold Exposure Test Method | IEC 60068-2-1 |
| Corrosion Test Method | IEC 60068-2-11, Test Condition Ka | IEC 60068-2-52, Test Condition Kb |
| Damp Heat Exposure Test Method | IEC 60068-2-30, Test Condition Db |
| Heat Exposure Test Method | IEC 60068-2-2 |
| Ingress Protection Test Method | IEC 60529:2001, IP56 |
| Packaged Product Shock Test Method | ASTM D4169 | GR-63-CORE, Section 4.1.1 |
| Rain Simulation Test Method | IEC 60068-2-18, Test Condition Ra, Method 1 |
| UV Resistance Test Method | IEC 60068-2-5, Test Condition B |
| Vibration Test Method | ASTM D4169 | IEC 60068-2-6 |
Packaging and weights
| Weight, net | 0.5 kg | 1.102 lb |
Regulatory compliance/certifications
| Agency | Classification |
AISG
|
Compliant |
| ROHS | Compliant/Exempted |
| UK-ROHS | Compliant/Exempted |
Product classification
| Product Type | RET actuator |
General specifications
| AISG Input Connector | 8-pin DIN Male |
| AISG Input Connector Quantity | 1 |
| AISG Output Connector | 8-pin DIN Female |
| AISG Output Connector Quantity | 1 |
| Color | Black |
Dimensions
| Height | 205 mm | 8.071 in |
| Width | 125 mm | 4.921 in |
| Depth | 50 mm | 1.969 in |
Electrical specifications
| Input Voltage | 10–30 Vdc |
| Adjustment Cycles, minimum | 10000 cycles |
| Adjustment Time, full range, maximum | 30 s |
| Electromagnetic Compatibility (EMC) | CFR 47 Part 15, Subpart B, Class A | EN 55022 |
| Interface Protocol Signal | RS-485 |
| Protocol | AISG 1.1 |
Material specifications
| Material Type | ABS |
Environmental specifications
| Operating Temperature | -40 °C to +70 °C (-40 °F to +158 °F) |
| Climatic Sequence Test Method | IEC 60068-2-14 |
| Cold Exposure Test Method | IEC 60068-2-1 |
| Corrosion Test Method | IEC 60068-2-11, Test Condition Ka | IEC 60068-2-52, Test Condition Kb |
| Damp Heat Exposure Test Method | IEC 60068-2-30, Test Condition Db |
| Heat Exposure Test Method | IEC 60068-2-2 |
| Ingress Protection Test Method | IEC 60529:2001, IP56 |
| Packaged Product Shock Test Method | ASTM D4169 | GR-63-CORE, Section 4.1.1 |
| Rain Simulation Test Method | IEC 60068-2-18, Test Condition Ra, Method 1 |
| UV Resistance Test Method | IEC 60068-2-5, Test Condition B |
| Vibration Test Method | ASTM D4169 | IEC 60068-2-6 |
Packaging and weights
| Weight, net | 0.5 kg | 1.102 lb |
Regulatory compliance/certifications
| Agency | Classification |
|
AISG
|
Compliant |
| ROHS | Compliant/Exempted |
| UK-ROHS | Compliant/Exempted |
